項目Item/型號Model |
HZS25 |
HZS35 |
HZS50 |
HZS75 |
HZS100 |
整機
Whole machine |
理論生產率(m³/h)
Theoreical productivity |
25 |
35 |
50 |
75 |
100 |
控制方式
control mode |
微機 Computer |
計量方式
Weighing mode |
電子秤 Electrical scale |
出料高度
Discharging height |
3.8 |
整機裝機容量
Whole machinery capacity |
55 |
85 |
110 |
150 |
180 |
攪拌機
Mixer |
攪拌機型號
Model of mixer |
JS500 |
JS750 |
JS1000 |
MT1500 |
MT2000 |
攪拌機功率
mixing power |
18.5 |
30 |
18.5x2 |
30x2 |
37x2 |
入料容積(L)
Charging volume |
800 |
1250 |
1500 |
2250 |
3000 |
出料容積(L)
Discharging volume |
500 |
750 |
1000 |
1500 |
2000 |
料徑碎石/卵石
Diameter of macadarn/pebble |
40-60 |
40-60 |
40-80 |
40-80 |
40-80 |
骨料儲供系統
Aggregate storage system |
配料秤型號
Batcher scale model |
PL800 |
PL1200 |
PL1600 |
DPL2400 |
DPL3200 |
配科種類
Types of ingredients |
2-3Piece(種) |
3Piece(種) |
3Piece(種) |
3-4Piece(種) |
4Piece(種) |
砂石儲料倉容積(m³)
Aggregate storage hopper volume |
3x2-3 |
3.4x3 |
5x3 |
8x3 |
15x3 |
計量范圍及精度
Weighing range & accuracy |
200-1500±2% |
200-2000±2% |
200-2500±2% |
200-3500±2% |
200-5000±2% |
理論生產能力(t/h)
Theoretical capacity |
80 |
100 |
140 |
190 |
260 |
粉料儲供系統
Powder storage |
粉料存儲能力
Powder storage capacity |
50x1 |
50x2 |
100x2 |
100x2 |
100x4 |
螺旋輸送機能力(t/h)
Screw conveyer capacity |
30 |
35 |
45 |
55 |
80 |
水泥計量范及精度
Cement weighing range&accuracy |
50-300±1% |
50-400±1% |
100-600±1% |
100-1000±1% |
100-1100±1% |
水外加劑緒供系統
Water addives storage system |
水計量范圍
Water weighing range |
50-150 |
50-200 |
50-350 |
50-450 |
50-500 |
水計量精度
Water weighing accuracy |
±1% |
液態外加劑量范國
Liquid additives weighing range |
5-20 |
5-20 |
5-20 |
5-30 |
5-60 |
液態外加劑量精度
Liquid additives weighing accuracy |
±1% |
