項目 Item/型號 Model |
YHZS25 |
YHZS35 |
YHZS50 |
YHZS75 |
整機
Whole machine |
理論生產率(m³/h)
Theoretical productivity |
25 |
35 |
50 |
75 |
控制方式
Control mode |
微機 Computer |
計量方式
Weighing mode |
電子稱 Electrical scale |
出料高度
Discharging height |
2.8~3.8 |
整機裝機容量
Whole machinery capacity |
50 |
80 |
100 |
140 |
攪拌機
Mixer |
攪拌機型號
Model of mixer |
JS500 |
JS750 |
JS1000 |
MT1250 |
攪拌機功率
Mixing power |
18.5 |
30 |
18.5×2 |
22×2 |
入料容積(L)
Charging volume |
800 |
1200 |
1500 |
1750 |
出料容積(L)
Discharging volume |
500 |
800 |
1000 |
1250 |
料徑碎石/卵石
Diameter of macadam/pebble |
40~60 |
40~60 |
40~80 |
40~80 |
骨料儲供系統
Aggregate storage system |
配料秤型號
Batcher scale model |
PL 800 |
PL1200 |
PL1600 |
PL2400 |
配料種類
Types of ingredients |
2Piece(種) |
2Piece(種) |
4Piece(種) |
4Piece(種) |
計量范圍及精度
Weighing range & accuracy |
200~1500±2% |
200~2000±2% |
200~2500±2% |
200~3500±2% |
粉料儲 供系統
Powder storage system |
粉料存儲能力
Powder storage capacity |
50×1 |
50×1 |
50×1 |
50×2 |
螺旋輸送機能力(t/h)
Screw conveyor capacity |
30 |
35 |
45 |
55 |
水泥計量范圍及精度
Cement weighing range & accuracy |
50~300±1% |
50~450±1% |
50~600±1% |
100~800±1% |
水外加劑 儲供系統
Water additives storage system |
水計量范圍
Water weighing range |
50~150 |
50~200 |
50~350 |
50~450 |
水計量精度
Water weighing accuracy |
±1% |
液態外加劑量范圍
Liquid additives weighing range |
5~20 |
5~20 |
5~20 |
5~30 |
液態外加劑量精度
Liquid additives weighing accuracy |
±1% |
